Maximize your solar investment with the Single Axis-20P. This rugged, 20-panel 1-axis tracker boosts energy yield by up to 30% in any environment.

Contact

描述

Open up to 30% even more energy return from your solar investment with our Single Axis-20P solar tracking system. Designed for 1-axis solar tracking, this tough 20-panel remedy keeps your modules straightened with the sunlight for optimal performance, also in difficult outside atmospheres.

Features and Benefits

  • High-precision 1-axis solar tracking: Our expensive formula ensures your panels track the sunlight with ≤ 1 ° accuracy, increasing power output and yield.
  • Heavy-duty construction: The framework makes use of Q235 steel, hot-dip galvanized for superior deterioration resistance – constructed to flourish outdoors for 25 years.
  • Optimized for 20-panel deployments: Supports panels (250-300W, 1650 x 992 mm) across a 33 m ² bracket location, delivering adaptable style for diverse website designs.
  • Enhanced wind resistance: Engineered to hold up against wind accelerate to 17 m/s with optional wind defense.
  • Consistently high output: Delivers a 15-30% energy rise versus repaired installing, maximizing your job’s return.
  • Precise and effective control: Tilt angle taken care of at 20 °, with a -45 ° to +45 ° tracking range for reputable, season-adaptive performance.
  • Low functional expenses: Consumes ≤ 0.25 kWh while supplying consistent movement and stability.
  • Certified comfort: Complies with CE, CQC, ISO9001, ISO14001, and OHSAS18001 requirements to ensure safety and quality.
  • Remote monitoring-ready: Equipped with RS485-MODBUS interface for combination right into contemporary solar plant management systems.

Wide Applications

This 1-axis solar tracking system is ideal for ground-mount solar ranches, utility-scale PV setups, and commercial roof selections where making the most of everyday yield makes all the difference. Its durable building and exact tracking capabilities make it perfectly fit for diverse climates – from deserts to high-wind regions.

Specifications

  • Mechanical (Tracking type, load capacity, wind/snow class, dimensions, weight, product, bearing life): 1-axis tracking, 20-panel capability (250 – 300W each), panel dimension: 1650 x 992 mm, bracket area: 33 m TWO, Q235 steel with hot-dip galvanizing, approx. 500 kg, design life: 25 years
  • Electrical (Motor kind & power, power usage, voltage range, tilt array, tracking rate, return boost): Power consumption ≤ 0.25 kWh, tilt angle 20 °, tracking range -45 ° to +45 °, yield increase 15-30%.
  • Environmental (Operating temperature, IP ranking, moisture, UV & corrosion resistance): Operates -40 ° C to +70 ° C, anti-corrosion with hot-dip galvanizing.
  • Performance (Energy increase vs. fixed, MTBF, reliability (% uptime), failure settings): Energy increase 15 – 30% vs. fixed.
  • Communications (Protocols (Modbus, TCP/IP, MQTT), remote debugging, OTA upgrade, API accessibility): RS485-MODBUS procedure for tracking and control.
  • Safety & Certifications (IEC requirements, CE/UL/ROHS, security interlocks, lightning defense): CE, CQC, ISO9001, ISO14001, OHSAS18001 accredited.

Technical Support

We support your job at every step, supplying thorough CAD versions, datasheets, and circuitry representations for smooth, easy combination.

Conclusion

When you pick SolPath, you acquire not simply a high-performance solar tracker, but years of design quality and service dedication focused on your long-term success.
