Open as much as 40% even more energy from every sunbeam with the Dual Axis-40P heavy duty 2-axis tracker. Developed for requiring solar jobs, this sophisticated system keeps your 40-panel range flawlessly lined up to the sun, so you see improved yield and faster ROI – all with well-founded dependability.

Features and Benefits

Rugged Construction: Built from top-quality Q235 steel with hot-dip galvanization, this tracker brushes off corrosion and deterioration for a much longer, stress-free service life.
Heavy-Duty Design: Holds up to 40 panels and 66 m two of component area – crafted to perform in massive tasks where toughness and endurance matter.
Dual Axis Precision: Tracks both azimuth and altitude (− 120 ° to +120 °, 0 ° to 60 °) with ≤ 1 ° precision, optimizing day-to-day and seasonal production for your website.
Smart Weather Protection: Withstands regular end up to 17 m/s and offers optional wind safety and security features, so you stay on the internet – even when the weather gets harsh.
Reliable, Low-Maintenance Operation: IP65 dirt and water protection means reliable exterior performance, from − 40 ° C frosts to +70 ° C heatwaves.- Certified Confidence: Complies with CE, CQC, ISO9001, ISO14001, OHSAS18001 for tested safety and security and quality you can trust.
Efficient Power Use: Draws simply ≤ 0.5 kWh, decreasing O&M and auxiliary expenses.

Wide Applications

This 2-axis tracker is excellent for utility-scale PV plants, ground-mounted solar farms, and terrain-challenging jobs where you require sturdy, scalable, and high-yielding options.

Specifications

Mechanical (Tracking type, tons capacity, wind/snow course, dimensions, weight, material, bearing life)
Tracking type: Dual axis.
Module number: 40.
Module size: 1650 mm × 992 mm.
Bracket location: 66 m TWO.
Weight: ≥ 2360 kg.
Material: Q235 steel, hot-dip galvanized.
Design life: ≥ 25 years.
Electrical (Motor type & power, power usage, voltage array, tilt variety, tracking speed, return boost)
Power usage: ≤ 0.5 kWh.
Tracking array: Azimuth − 120 ° to +120 °, Elevation 0 ° to 60 °
– Tracking accuracy: ≤ 1 °
– Energy increase: 20-40% over dealt with systems.
Environmental (Operating temperature level, IP score, humidity, UV & rust resistance)
Operating temperature: − 40 ° C to +70 ° C.
Protection Level: IP65.
Performance (Energy increase vs. repaired, MTBF, integrity (% uptime), failure settings)
Energy increase: 20-40% vs. fixed.
Communications (Protocols (Modbus, TCP/IP, MQTT), remote debugging, OTA upgrade, API gain access to)
Interface: RS485-MODBUS.
Safety & Certifications (IEC criteria, CE/UL/ROHS, security interlocks, lightning protection)
Certifications: CE, CQC, ISO9001, ISO14001, OHSAS18001.

Technical Support

We give extensive technological support, including CAD designs, datasheets, and wiring layouts to make your system combination seamless.

Conclusion

When you pick SolPath, you select quality crafted for your assurance – sophisticated 2-axis tracking, rugged resilience, and a boost in solar returns that makes every task shine.
